12-T A-PLATE #32 CHAIN SPROCKETS
For Ametric® No. 32 Single Strand Chain with
9.525mm Pitch
5.72mm Roller Width
6.35mm Roller Diameter
5.25mm Sprocket Single Tooth Width (B1)
40 mm Outside Diameter (Approximate) (de)
Without Hub (Plate Type)
12 mm Pilot (MPB) Bore +/-1mm (d1)
5.25 mm Total Width (A)
012 Teeth
NI 05242017 EH
